| 加工定制：是 | 品牌：KS | 型号：KS-2315D01W04A |
| 声道：单声道 | 是否有源：有源 | 材质：ABS |
| 规格尺寸(mm)：23*17*15.5MM | 驱动方式：电磁式 |
| APPLICATIONS ----- | ------ ITEM ------ | ||||||||||||||||
| RATED VOLTAGE-额定电压 | 1.5 VDC | 3.0VDC | ||||||||||||||
| OPERATING VOLTAGE-电压范围 | 1.0V ~ 3.0 VDC | 2.0V ~ 5.0 VDC | |||||||||||||||
| RATED CURRENT (max) 消耗电流* | max.20 mA | max.20 mA | |||||||||||||||
| SOUND PRESSURE LEVEL(min)-输出音压* | min.70dB | min.70dB | |||||||||||||||
| FUNDAMENTAL FREQUENCY-频率* | 400 ± 100 Hz | 400 ± 100 Hz | |||||||||||||||
| OPERATING TEMPERATURE RAGE-操作温度 | -10℃ to +60℃ | 10℃ to +60℃ | |||||||||||||||
| STORAGE TEMPERATURE RAGE-贮藏温度 | -10℃ to +70℃ | -10℃ to +70℃ | |||||||||||||||
| * Value applying at rated voltage | |||||||||||||||||
